X-SEAL® Transition Membrane

X-SEAL® Transition Membrane

H&B

$1.00
(No reviews yet) Write a Review
SKU:
XSEALMEMBRANE
SKU Number:
XSEALMEMBRANE
[PICKLIST] Roll Widths:
4"|6"|12"|18"|24"|36"|CUSTOM
[ASSET][SUBMITTAL] Submittal 1:
https://media.h-b.com/SUBMITTAL-X-SEAL-MEMBRANE.pdf
[ASSET][SDS] Safety Data Sheet (SDS) 1:
https://media.h-b.com/X-SEAL+Transition+Membrane+Film+SDS.pdf
[ASSET][SDS] Safety Data Sheet (SDS) 2:
https://media.h-b.com/X-SEAL+Transition+Membrane+Adhesive+SDS.pdf
[PICKLIST] Finishes/Materials:
Reinforced Polyolefin Laminated to Polypropylene
[PICKLIST] Roll Lengths:
75 ft.
[PDF][PART-1] Material Conformance - Text:

TECHNICAL DATA

  • Tensile Strength - ASTM D751-95
    • Machine Direction (Force) 130lbs
    • Cross Direction (Force) 124 lbs
  • Trapazoidal Tear Strength - ASTM D4533-91
[PDF][PART-2] Material Conformance - Text:
  • Machine Direction (Force) 46 lbs
  • Cross Direction (Force) 44 lbs
  • Mullen Burst - ASTM D751-95 180 psi
  • UV Exposure (2000 hours) - ASTM G154-98 >90%
  • Permeability
    • MVTR - ASTM E96 - B <0
    • [PDF][PART-3] Material Conformance - Text:
    .075 Perms1
  • Air permeability - TAPP-460 >5000 Sec/100cc
    • [PDF] Submittal Notes:

    NOTE: Please refer to Hohmann & Barnard installation instructions for more information.

    [PDF][PART-1] Submittal Short Description:

    X-SealTM Membrane is used to form a smooth transition from one plane to another when using ENVIRO-BARRIERTM Air and Vapor Barrier or ENVIRO-BARRIERTM VP Vapor Perm

    [PDF][PART-2] Submittal Short Description:
    eable Air Barrier. Use as a transition material where different substrates meet, or at beams, columns, and similar joints or connections to provide continuity.

    • Reinforced polyolefin base, laminated to a pol
    [PDF][PART-3] Submittal Short Description:
    ypropylene layer
  • Adhesive-backed with removable release liner

    • Standard Dimensions
    ▪ Available in widths: 4", 6", 12", 18", 24", 36",  other widths special order

    [PDF][PART-4] Submittal Short Description:
    r>▪ 75' long rolls

    Patents Pending

    Adding to cart… The item has been added

    X-Seal® Transition Membrane is a self-Sealing, self-adhering detail tape designed to work in conjunction with ENVIRO-BARRIER™ system. X-Seal® Membrane provides a durable seal around doors and windows and can be used to seal joints, seams, holes and other undesirable openings in wall systems. It resists the elements with unfailing performance and prohibits harsh environmental conditions from invading a structure.

    • Heavy-duty adhesive, made from a proprietary synthetic rubber compound, integrally bonded to a high strength woven polyethylene/polypropylene film.
    • Will not rot, crack, or drool like typical rubberized-asphalt adhesives
    • UV-resistant for up to 120 days
    • Asphalt-Free!

    DIMENSIONS:

    • Available in 3”, 4”, or 6” widths,
      other widths available upon request (up to 36”)
    • 75’ long rolls

    NOTE:

    • Manufactured from 45% post-industrial and/or post-consume recycled material.
    !
